F9500

Designed to maximize plant yeild and quality, the F9500 utilizes its “Blood Orange" rich yellow-red leaning spectrum to deliver efficency and reliability that punches well above its weight class.
Down load spec sheet

$999.00

Buy Now
<
>

SPECIFICATION

Input Power950W
Input Voltage120 - 277 VAC
Voltage Range100 - 305 VAC
Input Current7.9A
Min Power Factor>0.95%
THD<20%
Operation Frequency50/60Hz
Max Operation Temp (℉/℃)0 - 130 ℉ / -18 - 55℃
DimmingEXT 0-10V
Dimmer ModeEXT 0-10V,OFF/25%/75%/100%
Color Temperature3000K+6500K+660nm
B:G:R:FR395:876:1160:53
PPF (400-700) (μmol/s)2432
PPE (μmol/j)2.56
PPF (400-800) (μmol/s)2485
PF Eff (μmol/j)2.61

18in PPFD (μmol/s/m²)

1215
LifetimeQ90>54,000 hrs



PPFD MAP

Spectral Quatum Distribution


WHY THE F9500 SERIES

  • Easy Install Design
    Designed for simple installation. Suspension cables offer 4 and 2-point mounting options as well as rachet clips that provide an alternative mounting option.
  • Foldable Design
    The 180 degree foldable design feature can save your shipping cost
  • Built-in LED Driver
    Integrated design so there’s no secondary installation,more safer to use.
  • Control Capabilties
    Control each individual fixture with a 0-10V on-board dimmer or connect up to 50 LED fixtures with a controller.
